The Ultimate Off-Road Beast
The Cobra adopts a strong high-end four-bar linkage suspension and coil suspension, absorbing any bumps along the way down the trail. The 26X4.8 CST super fat tires and 750W gear hub motor, make riding more stable to suit all conditions.
Collapsible content
Size Chart
Cobra -- 5'5" ~ 6'5"
D7 -- 5'3" ~ 6'5"
-
A – total length82.6 1
-
B – handlebar height42.9 2
-
C – handlebar length27.6 3
-
D – wheelbase51.1 4
-
E – wheel diameter30.3
-
F – minimum seat height30.3 5
-
G – maximum seat height37 6
-
H – chain stay length19.7
-
I – frame stack32 7
-
L – head tube length5.1
-
N – standover height30.7
2 - Cobra: 44.5
3 - Cobra: 28
4 - Cobra:52
5 - Cobra: 20.9
6 - Cobra: 30.4
7 - Cobra: 25
Overview
80 Miles
Per Charge (maximum) *1
26x4.8
Super Fat Tire
Torque
Sensor
Hydraulic
Brakes
960 Wh
Samsung/LG Battery
1000 W
Geared Hub Motor
20+ Mph
Top Speed *2
400 lb.
Payload Capacity
1 - The range can be affected by several factors like rider weight, incline, and pedal-assist levels, etc.
2 - Reach speeds of up to 20 mph, No pedaling required.
Specifications
Frame
6061 Aluminum frame
Headset
Neco H383AEM 28.6*44*56*39.8
Fork
DASH-AIR-20 Inverted Fork 120mm lockout & rebound adjustable 8
Shock
DNM A0-38RC rear shock 190*45mm *9
Front wheel
M9CF-150 12G*150*15mm 26'' 36h *10
Rear wheel
MD-147 12G 214L 48v 1000w Himiway hub motor *11
Tires
Kenda X Himiway 26*4.5 *12
Battery
Samsung/LG 48V 20Ah
Motor
1000W brushless gear motor *13
Display
LCD display with Type-c charger
Throttle
Thumb throttle
Sensors
Torque sensor丨speed sensor丨brake sensor
Crankset
Crank arm: EB-01-242A-S1 170mm | Chain ring: 40T 104BCD narrow wide chainring *14
Freewheel
Shimano CS-HG41.8 11-34T *15
Chain
KMC Z8.3 EPT 122L
Groupset
Shimano acera M3020 8s *16
Front brake
Tektro HD-E350 hydraulic brake
Rear brake
Tektro HD-E350 hydraulic brake
Rotors
F:TR-203-52 R:TR-180-52 *17
8 - Cobra: Selle royal A054UE
9 - Cobra: EXA A5-RR1-KS 190*50mm
10 - Cobra: MB016F-QR 13G*255*256m 26'' 36h
11 - Cobra: MD-147 12G 214L 48v 750w Himiway hub motor
12 - Cobra: CST roly poly 26*4.8
13 - Cobra: 750W brushless gear motor
14 - Cobra: Crank arm: EB-01-242A-S1 170mm | Chain ring: 44T 104BCD CL55
15 - Cobra: Shimano MF-TZ500-7 14-28T
16 - Cobra: Shimano altus M310 7 speed
17 - Cobra: Tektro TR180-24 F:180mm R:180mm
Components
Stem
XF-827 alloy Ext:50mm *18
Handlebar
Promax HB-3188DB -W780 *19
Seatpost
SP-2003 30.9*350mm
Saddle
Selle royal A054UE *20
Pedal
Aluminum pedal
Lights
48V LED light
Kickstand
Heavy-duty aluminum kickstand
8 - Cobra: Promax MA-400 28.6*90*31.8mm
19 - Cobra: Promax HB-3188 22.2*31.8*700mm
20 - Cobra: Velo soft saddle
Other
Range
60-80 miles
Controller
48V/30A
Charger
US standard 3.0 A smart charger
Rider height
5′3″ ~ 6′5″
Weight
88.6 lb. (with battery)
Max. system weight
400 lb.
